5IK系列 90W
|
电机型号 Motor Model |
输出功率 Outout Power |
电压 Voltage |
频率 Frequenc |
电流 Current |
额定转速 Rated Speed |
额定转矩 Rated Torque |
启动转矩 Starting Torque |
运行电容 Capacitor |
|
|
齿轮轴型 Pinion Shaft |
圆轴型 Round Shsft |
W | V | Hz | A | r/min | MN.M | MN.M | UF/AC |
| 5IK90GU-CF | 5IK90A-CF | 90 | 1ph220 | 50 | 0.64 | 1350 | 643 | 459 | 5.0/450 |
| 60 | 0.71 | 1550 | 530 | 450 | |||||
| 5IK90GU-AF | 5IK90A-AF | 90 | 1ph110 | 50 | 1.26 | 1350 | 646 | 475 | 20.0/250 |
| 60 | 1.4 | 1550 | 525 | 489 | |||||
| 5IK90GU-SF | 5IK90A-AF | 90 | 3ph220 | 50 | 0.74 | 1350 | 625 | 2800 | / |
| 60 | 0.61 | 1550 | 527 | 2150 | |||||
| 5IK90GU-S3F | 5IK90A-S3F | 90 | 3ph380 | 50 | 0.42 | 1350 | 625 | 2660 | / |
| 60 | 0.35 | 1550 | 519 | 2030 | |||||
减速箱减速比/性能对照表 Gear Reductio/Performance Comparison
|
减速比 Gear Ratio |
3 | 3.6 | 5 | 6 | 7.5 | 9 | 10 | 12.5 | 15 | 18 | 20 | 25 | 30 | 36 | 40 | 50 | 60 | 75 | 90 | 100 | 120 | 150 | 180 | 200 | |
| 50Hz |
转速 Speed r/min |
450 | 375 | 270 | 225 | 180 | 120 | 135 | 108 | 90 | 75 | 67.5 | 54 | 45 | 37.5 | 33.7 | 27 | 22.5 | 18 | 15 | 13.5 | 11 | 9 | 7.5 | 6.75 |
|
转矩 Torque N.M |
1.563 | 1.88 | 2.6 | 3.125 | 3.91 | 4.69 | 5.1 | 5.86 | 7.03 | 8.44 | 8.8 | 10.55 | 12.66 | 15.19 | 16.88 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | |
| 60Hz |
转速 Speed r/min |
516 | 430 | 310 | 258 | 206 | 172 | 155 | 124 | 103 | 86 | 77.5 | 62 | 51.6 | 443 | 38.75 | 31 | 25.8 | 20.6 | 17.2 | 15.5 | 12.9 | 10.3 | 8.6 | 7.77 |
|
转矩 Torque N.M |
1.29 | 1.55 | 2.15 | 2.58 | 3.22 | 3.86 | 4.3 | 4.83 | 5.8 | 6.96 | 7.3 | 8.69 | 10.43 | 12.52 | 13.91 | 17.39 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | |
